Plytelių pjaustyklė WANDELI QX-ZD1200 automatinė su disku

Trumpai apie prekę

Prekė: Plytelių pjaustyklė WANDELI QX-ZD1200 automatinė su disku. Kategorija: Plytelių pjaustytuvai.

• Gamintojas: Wandeli
• Modelis: PRZECINARKA WANDELI QXZ-ZD 1200 + TARCZE
• Galia: 1550 W

Professional tool for precise tile cutting

The WANDELI QX-ZD1200 cutter is an advanced device designed for precise cutting of ceramic, stoneware and natural stone tiles. With automatic operating modes, robust construction and a set of professional diamond discs, the device delivers exceptional precision and efficiency. It is an ideal choice for tilers and construction crews.

Features and advantages:

✔ 3 operating modes:

• Automatic: self-cutting and return to the starting position.
• Semi-automatic: automatic cutting with stop when finished.
• Manual: full control over the cutting process.

✔ Powerful motor 4000 W – high speed up to 8000 rpm. /min enables fast and precise cutting of various materials.

✔ Angle and depth adjustment:

• Cutting at an angle of up to 45°
• Maximum cutting depth: 30 mm (90°), 20 mm (45°)

✔ Water cooling system: double nozzles reduce disc wear and reduce dust formation.

✔ Set of professional diamond discs: The set includes diamond discs with different properties, which allow you to:

• Fast cutting of stoneware and ceramic tiles,
• Precise finish without nicks,
• Dry and wet cutting depending on your needs.

✔ Light and durable construction: aluminum frame provides stability while maintaining low weight (43 kg).

✔ Easy transport and storage: compact dimensions and quick assembly/disassembly.

✔ The possibility of mounting two discs at the same time – allows cutting and chamfering the edges of tiles in one pass.

Technical data:

• Power supply: 230 V / 50 Hz
• Engine power: 4000 W
• Rotary speed: 8000 rpm /min
• Maximum disc diameter: 125 mm
• Maximum cutting thickness:

  At 90°: 30 mm

  At 45°: 20 mm

• Maximum cutting length: 1200 mm
• Table dimensions: 1350 x 350 mm
• Water pump: DC24V 36W, capacity 9 l/min
• Package dimensions: 1760 x 460 x 510 mm
• Net weight/gross: 43/50 kg

Application:

The WANDELI QX-ZD1200 cutter + disc set is the ideal solution for:

✔ Professional tilers,

✔ Construction team,

✔ Stoneseers and stoneware processing companies,

✔ Workshops dealing with the installation of large format tiles.

With its automatic cutting function, water cooling system, and set of high-quality diamond discs, the device ensures fast and clean cutting, without chipping or material loss.

Summary:

WANDELI QX-ZD1200 + set of discs is an innovative, automatic wet glaze cutter that combines high power, precision and versatility of applications. Thanks to the possibility of mounting two discs at the same time, adjusting the angle and depth of cutting and solid construction, it is an indispensable tool for demanding professionals.

If you are looking for equipment that will provide precision cutting, long service life and comfort, WANDELI QX-ZD1200 will meet your expectations!
