Relė be įtampos, WiFi valdiklis TUYA SMART L N

Trumpai apie prekę

Prekė: Relė be įtampos, WiFi valdiklis TUYA SMART L N. Kategorija: Automatizavimo moduliai.

• Gamintojas: Adelid
• Modelis: GNIAZDKO PRZEKAŹNIK DO PUSZKI BRAMY GARAŻOWEJ

Product code: MPD-B

The MPD-B relay performs a function analogous to a conventional contact, not generating voltages at its output. Its contactors can be opened or closed on the basis of a control signal, allowing the control of various devices that operate on the principle of impulse or are dependent on the state of contact (open/closed).

Applications include:

• Garage doors, doors, gates,
• Furnaces, controllers,
• Recuperation systems,
• Air conditioning systems,
• Alarm systems,
• Contactors and others.

✅ Technical data:

• Power supply: 100-240V AC,
• Output voltage: up to 240V AC or 24V DC (maximum 5A*),
• Maximum LED power: 150W (max 5A),
• Operating temperature: from -10 to 40°C,
• Connectivity: WiFi 2.4Ghz,
• Dimensions: 39x39x18 mm,
• Smartphone apps: Tuya / Smart life (available for Android and IOS),
• Compatible with voice assistants: Google Assistant, Amazon Alexa,
• Ability to create scenes and automate with TUYA Scene,
• Degree of protection: IP20.

✅ Relay functions:

• Pulse control in the range from 1s to 3600s (e.g. gate, stove, door, gate)
• Controllable with both AC (up to 240V) and DC (12-24V) outputs. Recommended input: AC (100-240V),
• reset button.

✅ Compatibility of the device:

• The relay can also control circuits of other devices powered by direct current (DC 12-24V) or alternating current (AC 100-240V).
• It is permissible to connect devices with power exceeding the maximum parameters of this relay, provided that the correct contactor is used.

✅ The set includes:

• 1x Mini Smart Switch relay,
• 1x User Manual.

An MPD module designed to turn a traditional circuit breaker or outlet into a smart device controlled by a smartphone!

✅ The most important features of the product:

• Thanks to small dimensions, the device fits seamlessly in a standard can,
• No gateways required, works directly via WiFi,
• The module fits most contacts and switches,
• Control your phone through the free Tuya or Smart Life app (Android and iOS)
• Compatible with both stable and monostable connectors (so-called. bells),
• State memory after power failure,
• Possibility of using in stair systems,
• Management range: unlimited (can be managed from anywhere on Earth with network to network),
• Control function by mechanical switch mechanism,
• Support for Google Home and Amazon Alexa voice systems,
• WiFi range: up to 30m (depending on ambient conditions)
• Reset button on the housing
• Remote On/Off: Control via mobile app.

✅ Control Home Appliances From Anywhere, Anytime with the TUYA App!

This smart Wi-Fi controller lets you freely control the operation or power disconnection of various household appliances. You can do this from virtually anywhere, no matter how far you are from home – all you need is an internet connection for the outlet via your router and a smartphone with the dedicated app. The setup itself is very easy and straightforward.

✅ Tuya Smart - application for Android and iOS.

Free application running on Android and iOS, thanks to which you can control the intelligent relay from anywhere. The application does not limit use to control one device, you can configure any number of relays and other smart devices. The application that works in Polish allows you to manage access to the smart home for family members and gives the possibility of granting access permissions to individual members.

✅ 5 steps to add an MPD driver to the app on your phone:

1. Download and install Tuya Smart app,

2. Sign up or log in to the app, then click the "+" icon and add your device.

3. When the outlet flashes quickly green, the app will search for the smart outlet itself. Click "add" to open the list of available devices.

4. Click "Add" to add the device to the app.

5. The addition process is underway, you can change the name of the device, which will allow you to identify its place, e.g. socket in the kitchen.

✅ Dimensions of the device:

• A: 20 mm,
• B: 39 mm,
• C: 39 mm.
