Relės modulis Sonoff Zigbee Ewelink, be įtampos, NO/NC kontaktai

Trumpai apie prekę

Prekė: Relės modulis Sonoff Zigbee Ewelink, be įtampos, NO/NC kontaktai. Kategorija: Automatizavimo moduliai.

• Gamintojas: Sonoff
• Modelis: MINI-ZBD

Intelligent Voltage-Free Relay Sonoff MINI-ZBD Zigbee 3.0 Ewelink – NO/NC module for Gates, Roller Shutters, Actuators

Turn traditional installations into a fully intelligent system with the Sonoff MINI-ZBD, a compact Zigbee 3.0 module with dry voltage-free contact (NO/NC).

This universal controller allows you to remotely manage garage doors, blinds, actuators, solenoid valves, LED lighting and many other low-voltage devices 12-48 V or 230 V. All from your phone, voice and automations in the Ewelink app.

The main advantages of the device:

• Zigbee 3.0 connectivity – stable, fast and energy-efficient communication (Zigbee gateway required)
• Voltage-free contact NO/NC – safe control of gates, roller shutters, valves and actuators
• Wide power supply range – 100 – 240 V AC or 12 – 48 V DC – universal for low and high voltage
• Voice control – Amazon Alexa and Google Assistant

• Zigbee router function – amplifies signal and range in mesh network
• Easy installation – compact dimensions (41 × 43 × 21,5 mm) – fits in a can
• Safety – overload protection, PC V0 housing, CE/FCC/RoHS certificates
• Integration with Home Assistant – full automation and scenes

Build your smart home with Sonoff

The Sonoff MINI-ZBD Zigbee 3.0 voltage-free relay is the heart of low-voltage and high-voltage automation.

Combine it with sensors, blinds, lighting and gates and create a system that really makes everyday life easier.

Elevate your smart home

Install the Sonoff MINI-ZBD module in a standard electrical box add remote control, schedules and voice control to the gate, roller shutters or actuators.

With the Ewelink app, your home responds exactly the way you want it. Comfortable, safe and stylish.

Why choose this device?

The relay combines wide voltage compatibility (AC/DC), dry NO/NC contact and stable Zigbee 3.0 communication.

It works without interfering with wiring, integrates with Home Assistant, Zigbee2MQTT, Alexa, and Google Assistant, and the Zigbee router feature strengthens the network throughout your home.

Simple installation, high power and local scenes make it an excellent solution for upgrading your garage, garden, heating or DIY automation.

Specification:

• Model: MINI-ZBD
• Power supply: 100 – 240 V AC, 50/60 Hz, max. 0,1 A or 12 to 48 V DC, max. 1 A
• Load: 24 V⎓2 A Maximum resistive load or 12/24 V⎓8 W
• Zigbee protocol: IEEE 802.15.4
• Net weight: 34,5 g
• Dimensions: 41 x 43 x 21,5 mm
• Color: white
• Housing material: PC
• Application: Inside
• Working temperature: from -10°C to 40°C
