Suvirinimo aparatas Magnum MIG 224 S-DP, MIG/MAG, TIG, MMA, dvigubas impulsas, 230V, 200A

Trumpai apie prekę

Prekė: Suvirinimo aparatas Magnum MIG 224 S-DP, MIG/MAG, TIG, MMA, dvigubas impulsas, 230V, 200A. Kategorija: Invertoriniai suvirinimo aparatai.

• Gamintojas: Magnum
• Modelis: 224 SDP

Professional Dual Pulse Synergistic Welding Machine For Demanding Users

Are you looking for a modern MIG/MAG welding machine with double pulsation function that will provide perfect welds, easy operation and wide working possibilities? The MAGNUM MIG 224 S-DP is an advanced semi-automatic welding machine designed for both professional workshops and ambitious individual users.

The device uses modern IGBT technology and intelligent synergistic programs, thanks to which the setting of welding parameters is fast, intuitive and extremely precise.

Why Choose the MAGNUM MIG 224 S-DP?

✔ DOUBLE PULSE Function – Perfect Aluminum Welds

Dual current pulsation allows for aesthetic, even, and strong welds, especially when welding aluminum and stainless steel. Dual Pulse technology reduces spatter and lowers the risk of overheating the material.

✔ Synergy – Easier Welding Settings

The welder automatically selects operating parameters based on material type, wire diameter, and material thickness. This saves significant time and ensures a stable arc, even for less experienced users.

✔ 4 Welding Methods in One Device

The device supports:

• MIG/MAG
• MIG/MAG PULSE
• MIG/MAG DOUBLE PULSE
• MMA
• TIG Lift

One welder allows you to perform practically all workshop and service tasks.

✔ Ideal for Aluminum, Stainless Steel, and Mild Steel

Dedicated synergy programs enable welding of:

• structural steel,
• stainless steel,
• aluminum AlSi and AlMg,
• copper,
• CuSi and CuAl brazing.

✔ Modern IGBT Technology

High-performance IGBT transistors ensure:

• stable arc,
• high efficiency,
• lower energy consumption,
• reliability during intensive work.

The most important technical parameters

• Power supply: 230V / 50-60 Hz
• MIG/MAG current range: 30 to 200 A
• MMA/TIG current range: 20 – 180 A
• Working cycle: 60%
• Supported wire diameters: 0.6 / 0.8 / 0.9 / 1.0 / 1.2 mm
• Weight: 12 kg
• Degree of protection: IP21S
• Technology: IGBT
• Synergy: Yes
• Pulse: YES
• Double Pulse: YES
• TIG Lift: YES
• 2T/4T/SPOT: YES

Synergistic welding programs

Smart settings for:

• carbon steel,
• stainless steel,
• aluminium,
• Soldering.

Regulation of inductance

Allows you to adjust the characteristics of the arc:

• soft arch = less chipping,
• hard arc = higher heat concentration.

Correction of arc length

Precise voltage regulation allows you to adjust the parameters to the welding position and operator preferences.

Operating modes 2T/4T/SPOT

• 2T – standard welding,
• 4T – comfortable work with long welds,
• SPOT – spot welding with time regulation.

MMA Functions

• Arc Force
• Hot Start
• Anti Stick
• VRD

The Magnum MIG 224 S-DP welder is perfect for:

• locksmith workshops,
• car services,
• production and repair of steel structures,
• assembly work,
• agricultural holdings,
• professional welding plants.

Comes with a set of

• Welding machine MAGNUM MIG 224 S-DP
• MIG/MAG holder MB24/3m
• MMA cable
• Bulk cable
• Set of rollers for steel and aluminum
• Steel guide
• Operating instructions

Benefits for the user

✅ Easier welding due to synergy

✅ Professional quality welds

✅ Possibility of welding aluminium by Dual Pulse method

✅ Stable arch and few chipping

✅ Universal workshop application

✅ Compact and mobile design

✅ Intuitive operation even for less experienced welders

MAGNUM MIG 224 S-DP – professional welding without compromise

Bet on modern technology, comfort of work and the highest quality of welds. Magnum MIG 224 S-DP is a versatile Dual Pulse synergistic welding machine that will meet the demands of professionals and provide excellent welding results in all conditions.

Specifications
