Suvirinimo aparatas SHERMAN DIGIMIG 200 HIT su baliono vežimėliu

Trumpai apie prekę

Prekė: Suvirinimo aparatas SHERMAN DIGIMIG 200 HIT su baliono vežimėliu. Kategorija: Pusiau automatiniai suvirinimo aparatai.

• Gamintojas: Sherman
• Modelis: 7813421 DIGIMIG 200 HIT

➡ Refurbished version of DIGIMIG 200 HIT with wheels and shelf ⬅

SHERMAN DIGIMIG 200 HIT is a professional, technologically advanced semi-automatic welding machine designed for welding by:

➡ MIG/MAG:

Arc welding in gas shields (CO2 or Argon+CO2) is one of the most commonly used processes for the production of welded structures. The semi-automatic welding process involves melting the edges of the welded object and the welding material (welding wire on a roll) with an electric arc produced between the welding wire fed by the handle and the welded material.

Available Modes:

• MIG MAN - MIG-MAG welding with manual settings,
• MIG SYN - MIG/MAG welding with synergistic settings,
• FLUX / FCAW - self-shielding wire welding. This is a similar welding process as MIG/MAG but does not require a gas cylinder. There is a thin layer of powder on the wire, which at the time of arc formation produces gas covering the working area.

➡ TIG LIFT DC - welding with a non-melting electrode (tungsten) in an inert gas shield (Argon) using an additional handle. In the TIG DC Lift mode, the arc glow occurs when the electrode with the welded element is contacted (the button in the handle does not arc, the gas is connected directly from the reducer to the handle). In TIG Lift DC mode, the current is constant.

➡ MMA - classic welding with wrapped electrodes (rutile, alkaline, acidic).

The SHERMAN DIGIMIG 200 HIT welding machine is used for welding:

✔ low alloy steels (MMA, MIG/MAG, TIG Lift DC),

✔ low carbon steel (MMA, MIG/MAG, TIG Lift DC),

✔ alloy steels (MMA, MIG/MAG, TIG Lift DC),

✔ acid-resistant steels (MMA, MIG/MAG, TIG Lift DC),

✔ aluminium and its alloys (MIG),

✔ other weldable metals and alloys.

The device has been designed for all kinds of welding work in automotive, locksmith, repair, industrial workshops etc.

LCD display allows accurate adjustment of welding parameters such as:

• Welding voltage display - V s
• Welding current display - m/min A
• Electrode wire diameter selection button - 0.6/0.8/0.9/1.0
• Source control button - 2T/4T/SPOT
• Multi-function knob. - A
• Welding voltage knob - V
• Welded material and protective gas selection button -CO2/MIX/FLUX/AL
• Welding method selection button - MIG/SYN/MMA/TIG
• Protective gas button
• Quick Wire Release Button

LIST OF SYNERGISTIC PROGRAMMES:

• Fe CO2 - welding of carbon steels in CO2 shield.
• Fe MIX - welding of carbon steels in Ar/ CO2 mixture cover. The recommended proportions of the mixture are 82% Ar18% CO2.
• FLUX - self-shielding wire welding.
• ALU - welding aluminum alloys with AlMg5 wire.

• ✔ REPAIR WORKSHOPS,
• ✔ AUTOMOTIVE INDUSTRY,
• ✔ LOCKSMITH WORKSHOPS,
• ✔ OF ALL BODYWORK REPAIRS,
• ✔ FACTORIES,
• ✔ FARMS,
• ✔ HOMEWORK,

AND WHEREVER RELIABILITY MATTERS!

✔ SYNERGY - is a very helpful feature available in professional welding equipment class PREMIUM. By setting the appropriate program or entering parameters, the device will independently select most welding settings, such as wire feed speed or appropriate voltage, according to the programmed data.

✔ SOLDERING - The device enables soldering, mainly used in the automotive industry to connect galvanized sheets together without burning the galvanized layer.

✔ INDUCTANCE ADJUSTMENT - function is useful during welding using the MIG/MAG method of thin elements, preventing them from burning out and soldering galvanized elements. Changing the inductance value also reduces the amount of welding chips during CO2 shielded welding. Thanks to the inductance adjustment, the welding machine is suitable for lutowelding. Depending on the model of the welding machine, the adjustment is automatic or can be adjusted manually.

✔ SPOT WELDING - consists in making on a small area of joining materials of small thickness. Most often, spot welding of sheet metal is carried out. This procedure is also referred to as one-sided welding.

✔ SPOOL GUN CONNECTOR - allows you to connect a special handle with space for an additional spool with wire.

✔ INVERTER TECHNOLOGY IGBT - is a modern technology based on bipolar transistors with an isolated gate. It combines the ease of control of field transistors with high breakdown voltage and switching speed of bipolar transistors. The use of IGBT technology has the effect of significantly extending the reliable operation of welding equipment.

✔ WIRE BURNING FUNCTION - BURN BACK - It is possible to adjust the time for which the voltage at the output of the device still occurs after stopping wire feeding. This feature prevents the welding wire from getting stuck in the welded material and prepares the end of the wire for the next arc.

✔ EUROCONNECTOR - allows you to quickly change the handle and allows you to change the polarity for welding with self-shielding wire.

✔ TWO-BAR 2T - pressing the button initiates gas outflow and welding current, releasing the button turns off welding current and gas outflow.

✔ FOUR-BAR 4T - pressing and releasing the handle button initiates gas outflow and welding current, re-pressing and releasing the button turns off the welding current and gas outflow.

✔ VRD - (Voltage Reduction Device) - reduces the resting voltage of the idle state on the electrode to a safe value. Provides shock safety when working in humid environments.

✔ ANTI-STICK - automatic shutdown of welding current in case of electrode sticking, which facilitates its removal.

✔ HOT START: facilitates electrode ignition by providing more welding current with each arc.

✔ ARC FORCE: facilitates the transfer of a drop of molten electrode to the welded material, preventing the arc from extinguishing when the drop of electrode contacts the welding lake

✔ GAS TEST – a function that allows you to switch on the solenoid valve itself without switching on the power source and wire feeder (this function is used to determine the value of the shielding gas flow and check the patency of the gas circuit.

✔ WIRE TEST – a function that allows you to start the wire feeder itself without switching on the power source and solenoid valve (this function is used when introducing electrode wire into the welding torch).

EFFICIENT OPERATION THANKS TO PROFESSIONAL WIRE FEEDER

The welder is equipped with a professional wire feeder, which guarantees stability and continuity of operation of the device

The 2-roll feeder allows precise extension of the welding wire excluding its slippage.

The display shows the FAST WIRE EJECTION button. Pressing the button causes the electrode wire to slide out quickly. It can be used when putting on a spool with wire in order to quickly introduce it into the welding torch.

➡ The device is equipped with overload protection, which increases its reliability.

❄ The device has a fan cooling system which significantly increases its efficiency.

⏩ TECHNICAL DATA:

• Power supply voltage: AC 230V 50Hz
• Maximum power consumption: 4.9 kVA
• Number of phases: 1ph
• Network security: 25 A
• Power supply frequency: 50 [Hz]

⏩ PARAMETERS OF THE DEVICE:

• MIG duty cycle: 200A / 60%
• MMA duty cycle: 180A / 60%
• TIG duty cycle: 200A / 60%
• Welding current MIG: 30 ÷ 200A
• MMA welding current: 25 ÷ 180A
• TIG welding current : 15 ÷ 200A
• MAXIMUM CURRENT CONSUMPTION MIG: 33 A
• MAXIMUM CURRENT CONSUMPTION MMA: 35 A
• MAXIMUM CURRENT CONSUMPTION TIG: 25 A
• WELDING VOLTAGE MIG: 15,5 – 24 V
• Idle voltage: 65V
• Efficiency: 60%
• Feeder: 2R
• Spool diameters with wire: 100 mm / 200 mm
• Max. Spool size: 5kg
• Wire diameter: 0.8/1.0/1.2 mm
• Degree of protection: IP21

⏩ OTHER:

• Housing protection: IP21
• Cooling: fan
• Dimensions: 436x215x324
• Weight: 10kg
• SPOT function: YES
• SYNERGY function: YES
• HOT START function: YES
• ARC FORCE function: YES
• 2T/4T function: YES
• SOLDERING function: YES
• TIG LIFT function: YES
• VRD function: YES

WHEN BUYING FROM US, YOU GET A WELDING MACHINE IN THE MANUFACTURER'S KIT CONTAINING:

• Welder SHERMAN DIGIMIG 200 HIT with wheels and shelf - 1pc.
• Welding torch MB15/3m - 1pc
• Electrode holder - 2 m - 1 pcs.
• Bulk cable - 2 m - 1 pcs.
• Operating instructions
• Guarantee card

SET OF 1 MIG INDUCTANCE MB15.

M.
