Suvirinimo inverteris MAGNUM MIG/MAG, DUAL PULSE, ALU SYNERGY, 4x4, 400V

Trumpai apie prekę

Prekė: Suvirinimo inverteris MAGNUM MIG/MAG, DUAL PULSE, ALU SYNERGY, 4x4, 400V. Kategorija: Pusiau automatiniai suvirinimo aparatai.

• Gamintojas: Magnum
• Modelis: U MI 352 DP SYN

✅Do you need a solid wire feeder in your equipment?

• Metal 4-roll feeder⚡

✅Do you need full control over the weld?

• INDUCTANCE reduces chipping and improves weld quality ⚡

✅Perfect synergy is essential for you?

• Programs for steel, aluminium and stainless steel - for the most demanding ⚡

✅Looking for high-power equipment?

• Operating current 350A in 60% cycle - adapted to every need ⚡

✅A 400V power supply is essential for you?

• Power supply at 400V - stable operation in all conditions ⚡

✅Do you weld a lot?

• Machine for large spools of wire long work without interruptions for material exchange! ⚡

✅ Do you need maximum control and precision?

• DUAL PULS gives Better transfer of binder to material

✅ Do you weld thin parts?

• FAST COLD – technology designed for precise welding of materials, excellent quality on thin sheets and precision elements

⏩Why MIG 352 DUAL PULS SYNERGY is the best choice?

✅wide range of applications - MIG/MAG 50-350A welding current, MMA 20-320A

✅multiple welding methods in one device – MIG/MAG, MMA, TIG LIFT

✅welding of steel, stainless steel, aluminium, copper and their alloys,

✅SYNERGY – automatic setting of welding parameters,

✅PULS & DOUBLE PULSE

✅MANUAL – full control for advanced users,

✅modern IGBT transistors – energy saving and reliability,

✅ 4-roller feeder (4x4) – smooth and stable wire feed,

✅chassis for gas cylinder,

✅regulated inductance,

✅built-in memory for saving your own settings - 20 channels,

✅adjustable wire feed speed,

✅FAST MIG program: fast welding

✅adjustable frequency and pulsation balance,

✅graphically presented approximate thickness of the welded material,

✅Additional functions: 2T/4T/S2T/S4T, HOT START, ARC FORCE, VRD.

⏩MEMORY OF ANY SETTINGS ON CHANNELS 1 TO 20

⏩WHAT WILL YOU FIND IN THE PACKAGE?

✔ Welding machine MAGNUM MIG 352 DUAL PULS SYNERGY

✔ MIG 24 welding torch with a length of 3m

✔ Bulk cable

✔ MMA electrode cable

✔ User Manual

⏩MAGNUM MIG 352 - READY FOR ANY CHALLENGE FROM STEEL TO ALUMINIUM

MAGNUM MIG 352 DUAL PULS SYNERGIA is an advanced inverter semi-automatic welding machine designed for precise welding of a variety of materials. With the ability to weld using the MIG/MAG, MMA PULS, TIG LIFT PULS method and spot welding, the device offers exceptional versatility and performance in professional applications.

The device allows welding with a single and double pulsation, and also has SYNERGY and MANUAL modes, thanks to which the user has full control over the welding process. With 20 channels of programmable memory, it is possible to store and recall your favorite welding settings.

MAGNUM MIG 352 DP Synergy has a compact design, four-roll wire feeder. It can be successfully used for any welding work in both industry and services. This device is recommended for both professionals and advanced amateurs who require the welding device to meet the highest standards and can take full advantage of its wide capabilities.

⏩LCD DISPLAY

The user-friendly interface is a huge advantage of this model. Thanks to this, advanced welding parameters are much simpler and more convenient. MIG is easy to use and already in the first contact with the function panel, the user can easily adjust the parameters.

Advanced welding parameters and excellent welding characteristics of the source translate directly into good welding quality.

⏩ SYNERGISTIC PROGRAMMES AVAILABLE

The device offers a wide selection of pre-programmed synergistic modes, adapted to different materials and shielding gases. Thanks to them, you get optimal settings of welding parameters without the need for manual selection – just choose the type of material and wire diameter.

✅Carbon and low alloy steels:

• Fe CO₂ – MAG welding in pure CO₂ shield
• Fe Ar 82% – MAG in Ar + 18% CO₂ mixture (for stable arc, smaller chipping)
• Fe Ar 92% – MAG in Ar + 8% O₂ mixture (for higher penetration, smoother weld)

✅Aluminium and its alloys:

• Al 99,5 Ar – pure aluminium, MIG with Ar cover
• AlMg4,5 Ar – aluminium alloy with magnesium (e.g. 5083)
• AlMg5 Ar – another variant of Al-Mg alloys
• AlSi5 Ar – aluminium alloy with silicon (e.g. 4045, 4047)

✅ Soldering and copper alloys:

• CuSi3 – soldering of galvanized steels, MIG with Ar cover
• CuAl Ar – soldering using Cu-Al alloys
• CuAl8 Ar – for more advanced applications with Cu-Al
• CuSi Ar 98% – soldering in Ar + CO₂ mixture
• CuAl Ar 98% – Cu-Al soldering in Ar + CO₂ mixture

✅Stainless steels:

• E308 Ar98% – stainless steel (e.g. AISI 304), MIG with Ar + 2% CO₂
• E316 Ar98% – high alloy steel, resistant to corrosion (e.g. AISI 316), MIG with Ar + 2% CO₂

✅Core wires:

• RutilFlux – rutile wires (with rutile filling)
• BasicFlux – alkaline wires (for more demanding applications)
• MetalFlux – wires with metallic filling, for alloy steels
• CrNi Flux – core wires for stainless steels

⏩ 4-ROLL WIRE FEEDER

Professional 4R wire feeder (4x4) - this is a reliable wire feeding regardless of the weight of the spool and the type of welding wire. The proven feeder mechanism has a big impact on the smoothness of wire feeding, and this already translates directly into the welding parameters of the device.

⏩MIGRATION WELDING WITH PULSE

In MIG welding with pulsating arc, the end of the electrode wire is accelerated melting and metal droplets are formed and peeled off. The resulting welding arc and metal flow characteristics from the end of the wire to the welding lake ensure better connector quality and less chipping. Pulse MIG welding also reduces the thermal deformation created during welding, making this method particularly recommended for welding stainless and acid-resistant steels.

• Better control over the amount of metal in the weld, making the welds cleaner and have less chipping.
• Less deformation of the material caused by heat, which is important especially for sensitive materials such as stainless steel and acid-resistant.
• Better weld quality and aesthetics.

⏩ DOUBLE PULSE MIG WELDING

Dual pulsation MIG welding is particularly useful for welding aluminum and its alloys. Thanks to the use of a double pulse and the appropriate setting of parameters, it is possible to obtain a weld significantly exceeding the quality of the weld obtained by the conventional MIG method.

• Welds of much better quality than with classic MIG welding are obtained.
• Better surface wetting, less defects and chipping, greater uniformity of the weld.
• The ability to precisely adjust the parameters, which gives the effect of visually and strength much better weld.

⏩SPOT

SPOT mode allows you to accurately set the welding duration at one point, allowing you to quickly and control the joining of thin materials without the risk of burning them out. Ideal for jobs that require aesthetics and repeatability – welds spot, but with surgical precision.

⏩Fast MIG

Program for fast MIG/MAG welding. Optimized for the pace of work without compromising on quality.

⏩Fast Pulse

The program combines Fast MIG speed with pulse arc control.

⏩Fast Twin

Fast Twin is a program for those who want to combine aluminum (and not only) at an express pace

⏩Fast Up

Special program for fast vertical welding by MIG-MAG method.

⏩Fast Root

A special program for one-sided butt welding, facilitating the proper formation of ridges.

⏩Fast Cold

Don't you like burns and chipping? Fast Cold is a cool calculation – it welds thin materials with limited heat supply, minimizing distortion. The effect? Welds so clean that it's a shame to grind them.

⏩CHASSIS FOR GAS CYLINDER

Place the gas cylinder on the chassis and enjoy the mobility of this flashing. No more tangled gas lines between the wheels. The gas cylinder is now where the machine is with you.

With the chain included in the set, you can secure the cylinder.

⏩WHEELS

The welder is equipped with two pairs of solid wheels, including front swivel wheels. They will make it easier to move the welding machine from place to place, increase your mobility, and also help transport any items placed on the chassis.

⏩POWER SUPPLY PARAMETERS

• Power Supply: 400V
• Welding methods: MIG, MAG, MMA, TIG LIFT
• Maximum welding current: 350A
• Technology: IGBT
• Working cycle: 60% 350A
• Net weight: 35kg
• Isolation class: IP21S
• Network security: 25A

⏩MIG/MAG WELDING PARAMETERS

• MIG/MAG welding current: 50 - 350A
• Wire diameter: 0,8 / 1,0 / 1,2 - depending on the type
• Reel size: D200, D300 up to 15kg
• Welding inductance: YES
• 2T/4T operation switch: YES
• Change of polarity: YES
• Synergic programmes: YES
• Point welding: YES

⏩WELDING PARAMETERS MMA

• MIG/MAG welding current: 20 - 320A
• Idle Voltage: 74V

⏩PARAMETERS WELDING TIG

• TIG Lift welding current: 20 - 320A

• MIG/MAG is a popular process both in hobby applications and in industry. It consists in welding with a hot melt electrode (in the form of wire wound on a spool) in a gas shield. The advantages of semi-automatic MIG/MAG welding include: ease of mastering the method at the basic level, high welding efficiency, high quality of the resulting weld.

• MMA - this is probably the best known and widespread welding method. The type and diameter of the wrapped electrode is selected depending on the type of material being welded. The MMA method does not require shielding gases. Welding is carried out using an electrode in a special sheath, which under the influence of the heat of the welding arc melts to form a weld. Melting sheath provides protection for the welding lake.

• TIG - TIG lift welding (non-melting tungsten electrode), inert gas shielding, with tactile arc ignition method.

• IGBT - welding machine is made in modern inverter technology using IGBT transistors. Thanks to this, it has stable welding parameters, enjoys high efficiency and, above all, ensures good welding quality.

• INDUCTANCE - weld face width control and reduction of welding chipping,

• SYNERGY - By setting the appropriate program or entering parameters, the device will independently select most welding settings, such as wire feed speed or appropriate voltage, according to the programmed data.

• 2T - pressing the button initiates gas outflow and welding current, releasing the button turns off welding current and gas outflow

• 4T - pressing and releasing the handle button initiates gas outflow and welding current, pressing and releasing the button again turns off the current

• S2T - a special two-bar with the possibility of setting the initial current IS (hot start) and final IE (crater filling) and their duration. Pressing the button initiates the hot start current, which lasts according to the set TS time, then changes to the set main welding current. Release of the button changes the current value to the crater filling current, which lasts according to the set time TE. After a while, these bows go out

• S4T - a special four-bar with the possibility of setting the initial current IS (hot start) and the final IE (crater filling). Pressing the button initiates a hot start current that lasts as long as the button is pressed. Release of the button causes the transition to the main welding current. Pressing the button again causes the current to pass to the value of the crater filling current, which lasts as long as the button is pressed. Release of the button extinguishes the arc and completes the process.

• SPOT WELDING - Super function for making even point welds or spot welding of thin plates on the tab.
