Suvirinimo pozicionierius CORMAK PS-180 su pedalu

Trumpai apie prekę

Prekė: Suvirinimo pozicionierius CORMAK PS-180 su pedalu. Kategorija: Pozicionieriai.

• Gamintojas: Cormak
• Modelis: CORMAK PS-180CZ

🔥 WELDING POSITIONER / WELDING TURNTABLE

CORMAK PS-180 – PRECISION WELDING | SPEED CONTROL | CONTROL PEDAL

CORMAK PS-180 is a compact welding positioner (welding turntable) designed for precise setting and turning of details during welding, assembly and production work.

The device significantly improves the comfort of the welder, allowing the weld to be carried in the optimal position without the need to manually rotate the detail. Perfect for welding pipes, sleeves, flanges, stubs and other cylindrical elements

✅ WELDING POSITIONER FOR DETAILS UP TO 10 KG

✅ ADJUSTABLE ROTATIONAL SPEED 1 TO 8 RPM. /MIN

✅ WORKING TABLE Ø200 MM WITH MOUNTING GROOVES

✅ TABLE TILT IN THE RANGE OF 0 TO 90°

✅ CONTROL PEDAL AS STANDARD

✅ RIGHT/LEFT ROTATION

✅ BUILT-IN INVERTER

✅ MASS SLOT FOR CONNECTING THE MASS CABLE

When welding cylindrical elements, the biggest problem is maintaining the right position of the weld.

The CORMAK PS-180 welding positioner automatically rotates the workpiece at an adjustable speed, so that:

✔ improves the quality of welds

✔ increases repeatability

✔ reduces operator fatigue

✔ speeds up the welding process

✔ improves work ergonomics

👉 The welder can only focus on driving the torch.

The built-in inverter allows you to smoothly adjust the rotation speed of the table.

✔ range 1 to 8 rpm. /min

✔ the ability to adapt to the type of weld

✔ ideal solution for TIG, MIG/MAG and assembly work

✔ full control over the process

👉 One welding turntable for many applications.

The work table can be manually tilted in the range of:

0° – 90°

Thanks to this, it is possible to set the detail in the most favorable position for welding.

✔ more comfortable work

✔ easier weld guidance

✔ greater accuracy

✔ better build quality

✔ welding of pipes

✔ welding of bushings

✔ welding flanges

✔ welding of stubs

✔ welding of cylindrical elements

✔ TIG welding

✔ orbital welding

✔ precision assembly

✔ serial production

✔ locksmith workshops

✔ production facilities

✔ renovation workshops

✔ BETTER WELD QUALITY

The fixed welding position improves aesthetics and build quality.

✔ GREATER EFFICIENCY

Less time spent turning the detail.

✔ COMFORT OF WORK

The operator does not have to manually manipulate the element.

✔ PRECISE REGULATION

Smooth change of rotational speed.

✔ UNIVERSALITY

It works well for both welding and assembly.

✔ COMPACT DESIGN

Ideal for workshops with limited space.

The product is made in accordance with applicable EU standards.

The device has CE certificate and EC declaration of conformity.

In addition, the PS-180 model is equipped with solutions that increase the safety and comfort of the operator.

• HORIZONTAL LOAD CAPACITY: 10 kg
• VERTICAL LOAD CAPACITY: 5 kg
• WORKING TABLE SIZE: Ø200 mm
• ANGLE OF INCLINATION: 0° ~ +90°
• ROTARY SPEED: 1 ~ 8 rpm. /min
• ROTATING POWER: 15 W
• TILTING: manual
• VOLTAGE: 220 V / 1PH / 50 Hz
• DIMENSIONS: 260 × 320 × 280 mm
• WEIGHT: 10 kg

✅ WELDING POSITIONER CORMAK PS-180

✅ WORKING TABLE Ø200 MM WITH MOUNTING GROOVES

✅ CONTROL PEDAL

✅ MASS SLOT

✅ 0 – 90° MANUAL TILT MECHANISM

✅ BUILT-IN INVERTER

✅ USER MANUAL / DTR

The three-jaw grip is not part of the set.

❓ FOR WHAT DETAILS IS THE PS-180 INTENDED?

For pipes, sleeves, flanges, stubs and other small components requiring controlled rotation during welding.

❓ CAN THE ROTATION SPEED BE ADJUSTED?

Yes. The positioner has a smooth adjustment in the range of 1 to 8 rpm. /min.

❓ CAN THE TABLE BE TILTED?

Yes. The tilt range is from 0° to 90°.

❓ IS THE THREE-JAW HANDLE INCLUDED?

No. The three-jaw handle is optional.

❓ FOR WHICH WELDING METHODS IS THE POSITIONER SUITABLE?

It is perfect for TIG, MIG/MAG welding and assembly work requiring controlled rotation of the workpiece.

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Brand	Cormak
Parametry	Manufacturer code	CORMAK PS-180CZ
Parametry	Packaging status	original
