Taškinio suvirinimo aparatas, 600W 80A, mėlynas, suvirinimo pistoletas, juvelyrikai

Trumpai apie prekę

Prekė: Taškinio suvirinimo aparatas, 600W 80A, mėlynas, suvirinimo pistoletas, juvelyrikai. Kategorija: Sandarikliai.

• Gamintojas: no brand
• Modelis: 82933

Description

This spot welding machine features a high-quality sheet metal housing that is highly durable. The power of 600 W enables spot welding in less time. Precise current regulation and tungsten needle head ensure professional, smooth and robust welding. It is the best partner for DIY and maintenance work!

Key Features

Solid and durable: The thickened sheet metal housing with lacquered finish is robust, resistant to wear, rust and corrosion, effectively protecting the internal components and extending the service life.

Good welding quality: Using the principle of high frequency plasma discharge, the high temperature electric arc is formed between the welded element and the tungsten needle, creating immediately a lake of molten metal at the welding site, enabling smooth, strong, fast and efficient welding.

Two operating modes: Depending on the type of welded element and the user's habits, there is a manual welding handle and a welding handle with a handle to choose from and replace.

Easy to carry: The device is lightweight, compact, and features a carrying handle on top for easy portability in the workplace.

Intelligent adjustment: Depending on the size of the welded element, solder weld and process requirements, the output current can be precisely adjusted using the rough adjustment knob and micro adjustment knob.

Good heat dissipation: Numerous cooling holes in the device ensure stable welding performance and prevent burnout after long-term operation.

Ease of use: One-button power switch, adjustment knob with clear scale and easy-to-read interface make it easy to operate.

Details

Footswitch: The precision of spot welding can be increased by controlling the welding time with a foot switch, which prevents interference during manual operation.

Non-slip pads: Four non-slip pads on the bottom ensure stable positioning of the device during operation and prevent scratching of the countertop.

Application

Can be used for fast welding of platinum, gold, coated gold, silver and steel. It is mainly used for welding jewelry ring clasps. Elements such as metal plates and tubes cannot be welded.

Method of use

1. Connect the power cord.

2. Install the hand-held welding gun/base, handle, foot switch and tungsten needle sequentially.

3. Turn on the power.

4. Adjust the height of the tungsten needle (the welding head should protrude about 4,8 cm).

5. Adjust the rough and precise adjustment knobs.

6. Adjust the welding distance.

7. Hold the welded element with the handle.

8. Press the foot switch with your foot (quickly move the foot away) and spot welding will be completed.

Specification

Material: Sheet metal

Color: Blue

Model: 80A

Welding Machine Type: Electric Spot Welding Machine

Power: 600 W

Plug: EU Standard

Welding Range: 0,5-1,5 mm/0,02-0,06 inch

Input Voltage: 220 V

Product Dimensions: 25,5 x 24,8 x 13 cm/10 x 9,8 x 5,1 inches

Package Dimensions: 37 x 28 x 18 cm/14,56 x 11,02 x 7,08 inches

Gross weight: 4,9 kg/10,8 lbs

Package Content: 1 x Jewelry Spot Welding Machine

1 x Power Cord

1 x Footswitch

1 x Tungsten Needle

1 x Handle

1 x Handheld Welding Gun

1 x Base

1 x User Manual in English

Other accessories

Notes

1. Before use For the welding machine, please check whether the supply voltage is compatible with the operating voltage. Connect the output wire of the welding machine to a screw of appropriate polarity (tighten the nut when connecting the output wire to the output polarity).

2. During operation, attach the element welded with a handle, close to the tungsten needle. Depending on the size and shape of the welded element, the distance between the tungsten needle and the welded element is usually 0,007-0,04 inches (approx. 1,8-2,2 mm). The outlet end of the tungsten needle must be sharp before and during use.

3. Do not place the welding machine in a damp place and it should be stored in a dry place.

4. Do not press the foot switch for long. It should be pressed and removed immediately. Long press of the switch and short circuit of the device can cause burnout of the internal circuit.

5. During welding, strong light is emitted. When welding, wear safety glasses and do not look directly at the welded element.

6. When pressing the foot switch, do not touch the metal part of the tungsten needle and handle at the same time, otherwise there will be a feeling of acupuncture.

7. Dismantling and repair by non-professionals is prohibited. There is high voltage inside.

8. Please note that only wires with a diameter of 0,5 to 1,5 mm can be welded. Do not weld wires of too large or too small thickness.

9. Before installation and use, please carefully read the instruction manual and pay special attention to the included safety instructions.

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Brand	no brand
Parametry	Maximum power	600 W
Parametry	Power supply	USB
Parametry	Manufacturer code	82933
Parametry	EAN (GTIN)	4069749082933
Parametry	Batteries included	no
Parametry	Packaging status	original
Parametry	Customs tariff code	85152100
