Trifazis nešiojamas dyzelinis generatorius HDM 7500 W

Trumpai apie prekę

Prekė: Trifazis nešiojamas dyzelinis generatorius HDM 7500 W. Kategorija: Elektros generatoriai.

• Gamintojas: HDM
• Modelis: GE11000D
• Įtampa: 400 V

Technical data

• Model: GE11000D
• Max. Performance: 230V 6,4 kW (1p); 400V 7,5 kW (~3p))
• Generator capacity: 230V 6 kW (1p); 400V 7 kW (~3p)
• Engine displacement: 498 cc
• Engine power: 10HP
• Rotary speed: 3000 rpm. /min
• Engine type: 1-Cylinder Diesel
• Start: ELECTRIC (just turn the key)
• Fuel: diesel
• Oil: 15w40
• Fuel tank capacity: 14 L
• Oil tank capacity: 1,65 L
• Built-in fuel level viewfinder
• Built-in voltage indicator: Voltmeter
• Single-phase sockets: 2 x 230V / 16A / 50Hz
• Three-phase socket: 1 x 400V / 16A / 50Hz
• Permanent current: 12V / max. 8,3 A
• Mute generator housing: steel, glued with soundproofing mat on the inside
• Starter battery: 20 Ah
• Protection rating: IP23M
• Type of generator winding: copper
• Acoustic power level in dB (A): 67
• Large transport wheels built into the housing: 4 pcs
• Transport handles: yes
• Weight: 160 kg
• Overall dimensions: 90x54x76 cm
• Instruction manual in Polish
• Burning 1l/h
• Constant frequency value 50Hz)

Advantages of the generator:

• MAXIMUM GENERATOR POWER for 400V 7,5 kW (3p)
• MAXIMUM GENERATOR POWER for 230V 6,4 kW (1p)
• VERY POWERFUL ENGINE WITH A MAXIMUM POWER OF UP TO 15KM
• VERY WELL MUTED: 75DB
• STEEL HOUSING WITH SOUNDPROOFING MAT MOUNTED INSIDE
• COPPER STATOR WINDING
• STATE-OF-THE-ART ELECTRONIC VOLTAGE STABILIZATION SYSTEM AVR
• EXHAUST EMISSION STANDARD: EURO V!!!!
• MEETS ALL SAFETY STANDARDS: DEGREE OF PROTECTION IP23
• ENVIRONMENTALLY FRIENDLY: MEETS ENVIRONMENTAL STANDARDS (TUV, CE, GS)
• SHORT-CIRCUIT PROTECTION
• HIGHEST QUALITY: MEETS ALL QUALITY CONTROL STANDARDS
• EXPANDED CONTROL PANEL (2X 230V; 1X 400V)
• EASY TO TRANSPORT THANKS TO WHEELS AND TRANSPORT HANDLE
• ENGINE VIBRATION ABSORBER,
• INSTRUCTION MANUAL in Polish!!

The power of the unit increases directly in proportion to the length of the stator core that is in it - thanks to which the GE11000D model has reached a maximum power of 7,5kW! When connecting the same devices to the unit compared to other weaker models, this one is much less loaded and thus the life of the device is significantly extended and fuel combustion is reduced, which makes the generator more economical.

Engine smooth running technology. Unlike most other generators that operate at variable speed per minute, our portable generator is equipped with a system technology of smooth engine operation, which, depending on the load of the generator, adjusts the fuel dose to keep the engine at a constant speed of 3000 r/min. It ensures constant engine speed regardless of the load that the unit is subjected to.

• 1x 230V plug
• 1x 400V plug
• Battery + 2 keys
• key to candles
• 4 large reinforced wheels
• instruction manual
