USB ZigBee vartai su Home Assistant antena

Trumpai apie prekę

Prekė: USB ZigBee vartai su Home Assistant antena. Kategorija: Centriniai blokai.

• Gamintojas: Automat-on
• Modelis: AUT000537

USB ZigBee gateway with Home Assistant antenna in the form of USB adapter is a simple and effective solution to build your home infrastructure of Zigbee devices. Thanks to it, you can connect devices from different manufacturers into one network and gain full control over Smart Home - locally, without cloud and unnecessary hubs.

The USB gateway works with Home Assistant, openHAB, Zigbee2MQTT and other popular open-source platforms, providing stable and fast operation.

Expand your smart home with ZigBee 3.0

ZigBee 3.0 is a wireless radio communication system very often used to support the network of smart home devices.

ZigBee devices should be used where certainty of operation of automated processes is extremely important.

Since automation management is carried out by the control panel (gateway, gateway), the programmed rules will be implemented regardless of access to the WiFi network, or in the absence of Internet connectivity.

An undoubted advantage of this form of communication is also speed of action. Devices using the ZigBee protocol in the event of a state change connect to the control panel in fraction of a second. For comparison, WiFi devices take about a few seconds to connect to a WiFi network and transmit the required signal through it. Therefore, ZigBee devices have a huge advantage when creating automation – intelligent rules.

Communication via the ZigBee protocol is distinguished by extremely low power consumption, as opposed to classic communication via Wi-Fi. This ensures long working time of battery powered devices, i.e. temperature and humidity sensors, flooding or opening/closing sensors for doors and windows.

The grid topology (mesh) provides stable communication between the gate and individual elements of the system, because each receiver is a transmitter at the same time. Damage to a single device does not stop the entire network.

Advantages of USB ZigBee gateway with Home Assistant antenna

• support for up to 32 devices working in Zigbee 3.0 technology
• Universal compatibility - works with Home Assistant, openHAB, Zigbee2MQTT and many systems (Linux, Windows, macOS, Raspbian, Ubuntu)
• implementation of programmed automation regardless of access to the WiFi network
• External antenna provides up to 3x longer range compared to standard Zigbee gates
• speed of operation - devices using the ZigBee protocol in case of state change connect to the control panel in fraction of a second.
• control from the mobile app from anywhere in the world
• cooperation with IOS/Android operating systems
• thanks to wireless data transmission does not require connection LAN cable
• secure and authenticated data transmission
• ability to be operated by multiple users
• Intuitive and simple operation
• easy installation - simply plug into the USB port

Zigbee/Bluetooth gateway specifications

• Data transfer protocol type - ZIGBEE 3.0 IEEE 802.15.4 / WiFi 802.11bgn / BLUETOOTH 4.2 802.11n
• possibility of voice control using external assistants, i.e. Google Home and Amazon Alexa
• Zigbee communication distance - Maximum 100 meters (open space)
• WiFi communication distance - Up to 80 meters (open space)
• Power Supply: DC 5V USB
• Systems: Linux, Windows, macOS, Raspbian, Ubuntu
• Assembly method: directly to the USB port
• Working temperature: -10 to 40 °C
• Dimensions: 56x56x23 mm
