Aprašymas
Trumpai apie prekę
Prekė: Vaizdo stebėjimo įrašymo įrenginys KENIK KG-NVR2018L-P-V2, 8 kanalų, IP kameroms. Kategorija: Garso įrašymo įrenginiai.
- Gamintojas: KENIK
- Modelis: KG-NVR2018L-P-V2
IP RECORDER KENIK KG-NVR2018L-P-V2
The most important features
- Support 8 IP cameras
- recording at resolutions up to 8MPX
- H.265+ compression
- max. bitrate: 80 Mbps
- Support 1 SATA hard drive up to 14TB
- built-in PoE switch 8x
- HDMI 4K video output
- ONVIF 2.6 support
- recording directly to the cloud drive (Google Drive, Dropbox)
- mobile preview on smartphone (Android, iPhone)
- free software in Polish to operate on your computer
- Cloud connection support (P2P)
- S.M.A.R.T function
Description
The modern Kenik KG-NVR2018L-P-V2 IP recorder is designed for small monitoring systems. It allows you to record video from 8 channels in a resolution of up to 8MPX. Support for Onvif version 2.6 also allows you to work with cameras from other manufacturers. High performance hardware and H.265+ compression allow you to limit the bandwidth and space needed on your hard drive. Another advantage is remote viewing on the phone from anywhere in the world and working in the cloud. The recorder allows you to record on Google Drive or Dropbox. The menu of the in Polish facilitates the operation and configuration of the necessary functions. The Kenik IP recorder is a great solution for systems that require safe and extremely effective monitoring of the facility.
Onvif
Onvif (Open Network Video Interface Forum) is an organization of CCTV manufacturers focused on the issue of standardization, a common protocol for these devices. This group was created to unify the protocol, i.e. the way of communication between devices of different suppliers. At present, the entire organization brings together about 450 companies and institutions from around the world.
Since its introduction, the Onvif standard itself has undergone successive stages of development and encountered various unexpected problems. It happened that two different devices with the implemented protocol did not work or their functionality was limited. Today, the standard is offered in version 2.6 and in the vast majority of cases allows for seamless integration of any devices.
Kenik Mobile preview
Thanks to the free Kenik Mobile application, we have the ability to remotely view the image from the camera on your mobile phone. It supports such systems as: Android, iOS. This gives us the ability to control what is happening in the monitored facility from anywhere in the world. When connected in the cloud, simply enter the camera ID number and enjoy remote access to your device.
Working in the cloud Kenik
Each Kenik IP camera has the ability to connect via the cloud. Thanks to this solution, without complicated configuration, every user can easily connect to the camera and see the image. The service is free.
VMS Pro software
VMS Pro is software that allows you to preview the image and manage the DVR on your computer. It allows you to connect several recorders located in different locations and preview the image from up to 128 cameras. In addition, creating an e-map makes it easier to browse and allows you to divide the system into zones. Support for up to 4 monitors at the same time will certainly help.
Video recording in the cloud
The Kenik recorder allows you to transfer photos and videos directly to a cloud drive. This provides additional backup to secure recordings. You can use popular Google Drive or Dropbox storage. All you need to do is have your own account on the selected server and configure the recorder accordingly to enjoy additional storage of photos and videos on a virtual disk. It is a convenient way to save and view important data.
Intelligent compression H.265+
The latest image compression standard allows you to reduce the bandwidth and amount of data on your hard drive by 50% compared to H.264+. While maintaining the same image quality, we can save even more recordings.
Technical specification
- Model: KG-NVR2018L-P-V2
Video/audio inputs
- IP video input: 8x
- Audio input: N/A
Video/audio outputs
- HDMI: 1x 4K (3840 × 2160) /30Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60H
- VGA: 1x 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- Audio: N/A
Recording
- Video compression: H.265+/H.265 /H.264+/H.264
- Resolution: 8MP/5MP/4MP/3MP/1080P/720P/D1/CIF/QCIF
- Video Bitrate: 64Kbps~10Mbps
Playback and backup
- Playback Mode: Smart/ Normal / Labels / Events / Image Playback / Log
- Playback: 1-channel 8Mp@30fps 2-channel 6Mp@30fps 2-kan 5Mp@30fps 3-kan 4Mp@30fps 6-kan 1080P@30fps
- Synchronous playback: up to 8 can.
- Backup: USB/Network
Advanced
- Intelligent motion detection: intruder detection, line crossing, area entry/exit, fast movement, object leaving/disappearing, parking detection, assembly detection, wandering detection, face detection, human/vehicle detection, blur and scene change detection, sound detection
- Intelligent playback: line crossing/intruder detection/motion detection/face detection/human detection/vehicle detection
- Cloud recording: Yes (Google Drive, Dropbox, FTP)
- Update via cloud: Yes
Network
- Inbound bandwidth: 80Mbps
- Outgoing bandwidth: 80Mbps
- Network interface: 1x RJ-45 10/100 Mbps
- Protocols: HTTP, HTTPS, TCP/IP, IPv4, UPNP, RTSP, UDP, SMTP, NTP, DHCP, IP Filter, DDNS, FTP, P2P, ONVIF 2.6
- Mobile preview: IOS (iPhone, iPad), Android
Hard Drive
- SATA: 1x
- Capacity max.: up to 14TB
External interfaces
- PoE: 8x RJ45 10 /100 Mbps
- PoE power: 45W (30W per port)
- USB: front panel: 1x USB 2.0; rear panel: 1x USB 2.0
General
- Power Supply: DC48V 2.5A
- Power consumption: ≤10W (without HDD and PoE)
- Working temperature: -10°C~+55°C / 10%~90%RH
- Dimensions(Sz×G×W): 250x230x45mm
- Weight (without HDD): ≤1.7Kg
Specifications
| Group | Name | Value |
|---|---|---|
| Parametry | Condition | new |
| Parametry | Invoice | With VAT invoice |
| Parametry | Manufacturer code | 51238 |
| Parametry | Brand | KENIK |
| Parametry | Model | KG-NVR2018L-P-V2 |
| Parametry | Product weight with unit packaging | 1.7 kg |
| Parametry | Product width | 25 cm |
| Parametry | Product height | 4.5 cm |
| Parametry | Product depth | 23 cm |
| Parametry | Product weight | 1.7 kg |
| Parametry | Number of supported cameras | 8 |
| Parametry | Maximum recording resolution | 8 Mpx |
| Parametry | Installed disk capacity | 0 TB |
| Parametry | Maximum number of supported drives | 1 |
| Parametry | Maximum capacity of drives | 14 TB |
| Parametry | Technology | IP |
| Parametry | Video compression | H.265+ |
| Parametry | Number of USB ports | 2 |
| Parametry | Network interface | RJ-45 10/100 |
| Parametry | EAN (GTIN) | 5908231257826 |
| Parametry | Packaging status | original |
| Parametry | Certificates of conformity | CE |
| Parametry | Video outputs | HDMI,VGA |
| Parametry | Functions | phone app,motion detection,advanced search |
