Vandens šildytuvas FLOWAIR 32,7 kW su valdikliu ir tvirtinimo laikikliu

Trumpai apie prekę

Prekė: Vandens šildytuvas FLOWAIR 32,7 kW su valdikliu ir tvirtinimo laikikliu. Kategorija: Oro šildytuvai.

• Gamintojas: Flowair
• Modelis: LEO S3 ZESTAW

Water heater FLOWAIR is a device made mainly for heating rooms and utility facilities, workshops, shops, warehouses. The device has a high heating efficiency and a solid construction, thanks to which it works for many heating seasons!

✅ SPECIFICATIONS:

• Max. air flow rate 1800 m3/h
• 3-stage capacity adjustment 1000/1400/1800 m3/h
• Heating power range 1,7 –32,7kW
• Nominal heating power(70/50/16oC. III gear) 12,3kW
• Max. Power consumption: 0,6A
• Max. Power consumption: 130W
• IP/Isolation class: 54/F
• Max. sound pressure level: 56,3dB
• Max. sound power level: 71,4dB
• Horizontal range at a limit speed of 0,5 m/s - 12,5m
• Vertical range at ΔT = 5oC, at a limit speed of 0,5 m/s - 4,9m
• Max. temp. heating water - 120°C
• Max. working pressure 1,6MPa
• 1/2” connection
• Max. Operating temperature 60°C

✅THE SET INCLUDES:

• Water heater
• Assembly console (wall or ceiling mountable)
• TS controller

✅LEO HEATER THIS IS IT!

LEO water heaters are equipped with a next generation 3-speed fan, with operating characteristics allowing for a wider range of performance regulation and thus heating power of the heaters. This means greater functionality and better operating parameters.

The housing is made of light and durable EPP material (foamed polypropylene).

The specially designed console allows vertical mounting of the device on narrow poles and partitions. Mounted vertically to the camera allows it to be mounted in parallel at different angles of the wall. Special underfloor brackets allow for ceiling mounting.

✅ TS DRIVER INCLUDED:

• It allows you to choose one of the three fan gears and allows you to control the valve actuator depending on the ambient temperature.
• If the temperature is lowered below the user's set temperature, the valve with the agent opens and closes when it is reached.
• TS allows you to set two fan modes: continuous: after reaching the set temperature, the fan continues to operate, intermittent: the fan stops when the set temperature is reached.
• The TS controller also allows you to set the heater operating mode: HEAT, FAN, COOL.
• Since the thermostat is part of the temperature sensor, it should be installed in such a place of the room that it is not exposed to factors that could disturb its measurement (e.g. solar radiation)

✅ MOUNTING BRACKET INCLUDED!

The LEO heater comes with a mounting console, allowing you to mount the device both vertically and ceiling.

The swivel console allows for easy installation at various angles for vertical and horizontal partitions.

✅STRONG UNIVERSAL HEATER!

The heater is characterized by a simple and durable construction and can be used in many facilities - it is mainly suitable for:

• workshops and production rooms,
• warehouses,
• shops,
• office rooms,
• greenhouses,
• churches,
• and for many large rooms
