Vieno kanalo Wi-Fi nuotolinio valdymo pultas SHELLY Smart Gen3

Trumpai apie prekę

Prekė: Vieno kanalo Wi-Fi nuotolinio valdymo pultas SHELLY Smart Gen3. Kategorija: Automatizavimo moduliai.

• Gamintojas: Shelly
• Modelis: S3SW-001X16EU

Shelly 1 Gen3 is not just a controller – it’s a full-fledged smart home hub that offers unparalleled control, flexibility and security. Easily integrated into existing infrastructure, this controller allows you to create advanced automation systems without having to invest in expensive solutions. With Shelly 1 Gen3, you can transform your home and office into smart, energy-efficient, and comfortable spaces that respond to your needs.

• Manufacturer: Shelly
• Model: 1 Gen3
• Dimensions: 37 x 42 x 16 mm
• Weight: 26 g
• Maximum torque of screw terminals: 0.4 Nm
• Cable cross-section: 0.2 to 2.5 mm² (fixed, cable and bootlace fittings)
• Cable length without insulation: 6 to 7 mm
• Assembly: wall console / flush-mounted box
• Housing material: plastic
• Color: blue
• Ambient temperature during operation: -20°C to 40°C
• Ambient humidity during operation: 30% to 70% RH
• Maximum height of position: 2000m
• Power source: 110-240 V~24-48 V⎓12 V⎓
• Power consumption: < 1.2 W
• Maximum switching voltage: 240 V~30 V⎓
• Maximum switching current: 16 A (240 V~) 10 A (30 V⎓)
• Internal temperature sensor: Yes
• Wi-FI protocol: 802.11 b/g/n
• Wi-Fi radio frequency: 2401-2483 МHz
• Maximum RF Wi-Fi power: < 20 dBm
• Wi-Fi range: up to 50 meters in open space, up to 30 meters in enclosed space (depending on conditions)
• Bluetooth version: 4.2
• Bluetooth radio frequency: 2400 - 2483.5 MHz
• Maximum RF Bluetooth power: < 4 dBm
• Bluetooth range: up to 30 meters in open space, up to 10 meters in closed space (depending on conditions)
• CPU: ESP-Shelly-C38F
• Flash memory: 8 MB
• Number of schedules: 20
• Webhooks (URL actions): 20 with 5 URLs per hook
• Ability to extend Wi-Fi coverage: Yes
• BLE gateway: Yes
• Scripts: Yes
• MQTT: Yes
• Encryption: Yes

✔ Comprehensive control: With Wi-Fi and Bluetooth, the Shelly 1 Gen3 allows you to remotely manage a wide range of home and office devices, giving you complete control over your lighting, gates, or irrigation, without the need for costly modifications.

✔ Performance and reliability: The new processor and 8 MB of memory ensure smooth and fast operation, while rugged terminals and support for loads up to 16 A guarantee stability and longevity.

✔ Easy integration without additional HUB: Compatibility with popular platforms such as Alexa, Google Home and protocols including KNXnet/IP allows for easy adaptation to existing home infrastructure.

Shelly 1 Gen3 is an advanced intelligent driver supporting Wi-Fi that revolutionizes the way you manage your home and office. Equipped with a dry 1-channel contact with a load capacity of 16A, this versatile controller allows you to remotely control a wide range of household appliances and office equipment, regardless of where you are. Upgrade standard electrical cans, outlets, and light switches without the need for complicated installations.

Shelly 1 Gen3 is equipped with a new ESP-Shelly-C38F processor with 8 MB of memory, which significantly increases its performance and efficiency. Increased durability of terminals and a high level of security guarantee reliable operation for many years. The Wi-Fi range booster and built-in Bluetooth gateway provide a stable connection, allowing you to quickly and seamlessly manage your devices throughout your home.

You don't need an additional HUB to use Shelly 1 Gen3. The controller is fully compatible with the Shelly Smart Control app, various home automation protocols, and popular voice platforms and assistants such as Alexa and Google Home. Additionally, Shelly 1 Gen3 supports KNXnet/IP communication, making it an ideal solution for advanced automation projects.

Shelly 1 Gen3 is the perfect choice for lighting automation, garage door management, upgrading older appliances and many other applications. With the ability to set custom schedules, scenes, and integrate with other Shelly devices, you can create an intelligent system that adapts to your lifestyle. Automate garden irrigation, control the temperature in your home or manage lighting, all remotely and effortlessly.

Shelly 1 Gen3 provides a high level of security with advanced encryption. With support for various security protocols, you can rest assured that your data and devices are protected at the highest level. In addition, the device looks stylish and minimalist thanks to its compact dimensions and blue color. Invest in Shelly 1 Gen3 today and discover a new dimension of comfort and control over your surroundings!

Specifications
